Specifications

◇Rated current In: 10A, 16A, 25A, 32A

◇Pole number: 2P

◇Rated voltage Ue: AC 230V

◇Rated frequency: 50Hz

◇Rated overload breaking capacity: 1.5 KA

◇Rated shock withstand voltage: 4 KV

◇High-voltage insulation:  2KA/1 min

◇Tripping style: Overload tripping

◇Mechanical life: 10000 times

◇Electrical life: 8000 times

◇Protection level: IP20

◇Fiducial temperature: 30℃

◇Ambient temperature: -5℃ to +40℃

◇Storage temperature: -35℃ to +70℃

◇Resistance to damp heat: 2 types(temperature 55℃,relative humidity 95%)

◇Installation type:Screw fastening card mounting with panel

◇Terminal wiring capability: 2.5mm²

◇Flame retardant grade: V-0

◇Tightening torque: 2.0N*m  22In-Ibs

◇Pollution degree: 2
