Applications
SKD-D PV DC moulded case circuit breaker is designed to provide overcurrent protection within appliances or electrical equipment, where a branch circuit protection is already provided or not required.
Devices are designed for DC control circuit applications, widely used in solar power system.
Specifications
Rated Current In(A) | 125 | 250 | 400 | |
63, 80, 100, 125 | 160, 200, 225, 250 | 320, 400 | ||
Rated Operating Voltage Ue (V DC) | 3P 750 | 4P 1000 | ||
Rated Insulation Voltage Ui (V DC) | 1000 | |||
Rated Impact Voltage Uimp (kV) | 8 | |||
Ultimate Breaking Capacity Icu (kA) | 25 | |||
Tripping Type | Thermo-magnetic | |||
Use Altitude (m) | ≤2000 | |||
Ambient Temperature | -20℃~+70℃ | |||
